Application Category

Power Unit(xEV)

① Power Control Unit/②. On-Board Charger ① Power Control Unit/②. On-Board Charger ③ Battery Management System

1. Power Control Unit/2. On-Board Charger

  Surface Mounting Type Leaded Type
General Purpose / Resistors RK73BRK73H
High Precision / Resistors RK73G
High Precision & High Reliability / Resistors RS73, RN73H
Wide Terminal / Resistors WK73R

High Power Rating / Resistors WK73R (High Power)SLRMWS

Surge Resistance & Pulse Resistance / Resistors SG73SG73SSG73PSG73GWG73

High Heat Resistance & Pulse Resistance / Resistors HSG73P

High Voltage & Voltage Sensing / Resistors HV73VHVD
RCR
Precharge & Discharge / Resistors   BGRVBWRV,
BSRV
Anti-sulfurization / Resistors RK73B-RTRK73H-RTRK73G‐RTRK73Z-RT,
SR73-RTWK73-RTWK73-RT (High Power)SG73-RT,
SG73S-RTSG73P-RTHV73V-RT

Current sensing / Low Resistance Resistors UR73VSR73WK73SWU73TLRTLR (Small Size),
TLR (High Power)TLRHSLPSJ2PSL2PSG4PSF4

Circuit Protection / Varistors NV73DLNV73DS
Circuit Protection / Fuses TF16VN
Temperature Sensing & Temperature Compensation / Thermal Sensors SDT73VLT73V

Jumper / Jumpers RK73ZTLRZ


3. Battery Management System

  Surface Mounting Type Leaded Type
General Purpose / Resistors RK73BRK73H
High Precision / Resistors RK73G
High Precision & High Reliability / Resistors RS73, RN73H
Wide Terminal / Resistors WK73R

High Power Rating / Resistors WK73R (High Power)SLR

Surge Resistance & Pulse Resistance / Resistors SG73SG73SSG73PSG73GWG73

High Voltage & Voltage Sensing / Resistors HV73VHVD

Precharge & Discharge / Resistors   BGRVBWRV,
BSRV
Anti-sulfurization / Resistors RK73B-RTRK73H-RTRK73G‐RTRK73Z-RT,
SR73-RTWK73-RTWK73-RT (High Power)RS73-RT,
SG73-RTSG73S-RTSG73P-RTHV73V-RT

Current sensing / Low Resistance Resistors UR73VSR73WK73SWU73TLRTLR (Small Size),
TLR (High Power)TLRHSLHS

Circuit Protection / Varistors NV73DLNV73DS
Circuit Protection / Fuses TF16VN
Jumper / Jumpers RK73ZTLRZ
